#include <EEPROM.h>

#include <Wire.h>               // I2C support

#include <Servo.h>

// Motor Variables

int Motor1F = 5;

int Motor1R = 10;

int Motor1PWM = A9;

int Motor2F = 19;

int Motor2R = 20;

int Motor2PWM = 6;

int Mot1State = 0;

int Mot2State = 0;

// Servo Variables

//

Robot3DoTBoard Robot3DoT;       // instantiated as Robot3DoT at end of class header

/*

* Command Example

* Step 1: Assign new command mnemonics ID numbers

*         In our example we will be adding 3 custom commands (2 new and one predefined).

*         The predefined MOVE command is intercepted and our robot unique code is to be

*         run instead. The MOVE command mnemonic ID 0x01 is already defined in Configure.h

*         The next two commands are new and assigned to the first two addresses in the

*         custom command address space 0x40 – 0x5F.

*/

#define DYNSTAT       0x41

const uint8_t CMD_LIST_SIZE = 2;   // we are adding 3 commands (MOVE, BLINK, SERVO)

/*

* Command Example

* Step 2: Register commands by linking IDs to their corresponding command handlers

*         In our example when the MOVE command is intercepted the moveHandler is to be run.

*         In a similar fashion the BLINK command calls the blinkHandler and SERVO the

*         servoHandler.

*/

void moveHandler (uint8_t cmd, uint8_t param[], uint8_t n);

void dynstatHandler (uint8_t cmd, uint8_t param[], uint8_t n);

Robot3DoTBoard::cmdFunc_t onCommand[CMD_LIST_SIZE] = {{MOVE,moveHandler}, {DYNSTAT,dynstatHandler}};

/*

* Telemetry Example

* Step 1: Instantiate packet

*         In our example we simulate a current sensor wired to MOTOR 2. MOTOR2_CURRENT_ID

*         is defined as 0x02 in Configure.h

*         To simulate the data stream coming from the sensor we will read ATmega32U4

*         Register OCR4D which controls the duty cycle of MOTOR 2.

*/

Packet motorPWM(MOTOR2_CURRENT_ID);  // initialize the packet properties to default values

void setup()

{

Serial.begin(19200);               // default = 115200

Robot3DoT.begin();

// Initialize Motor To Off

pinMode(Motor1F, OUTPUT);

pinMode(Motor1R, OUTPUT);

pinMode(Motor1PWM, OUTPUT);

pinMode(Motor2F, OUTPUT);

pinMode(Motor2R, OUTPUT);

pinMode(Motor2PWM, OUTPUT);

digitalWrite(Motor1F,LOW);

digitalWrite(Motor1R,LOW);

digitalWrite(Motor2F,LOW);

digitalWrite(Motor2R,LOW);

Robot3DoT.setOnCommand(onCommand, CMD_LIST_SIZE);

/* Telemetry Example

* Step 2: Modify default values assigned to internal properties as needed.

*         Before a packet is created and sent, it is qualified. Specifically,

*         the data in a packet must change by some amount from the previous

*         packet and may not be sent with at a period less than some value.

*         In most cases you can leave these values at their default values.

*/

}

void loop()

{

Robot3DoT.loop();

// Set Motor State to the Telemetry Read Value

if (Mot1State == 1){ digitalWrite(Motor1F,HIGH);

digitalWrite(Motor1R,LOW);

} else if (Mot1State == 2) { digitalWrite(Motor1F,LOW);

digitalWrite(Motor1R,HIGH);

}                                 else {digitalWrite(Motor1F,LOW);

digitalWrite(Motor1R,LOW);}

if (Mot2State == 1){  digitalWrite(Motor2F,HIGH);

digitalWrite(Motor2R,LOW);

} else if (Mot2State == 2) { digitalWrite(Motor2F,LOW);

digitalWrite(Motor2R,HIGH);

}                                 else {digitalWrite(Motor2F,LOW);

digitalWrite(Motor2R,LOW);}

// Read IMU Settings

// Set Servos to IMU Setting

}

/*

* Command Example

* Step 4: Write command handlers

*/

/*

* User Defined Command BLINK (0x40) Example

* A5 01 40 E4

*/

/*

* Override MOVE (0x01) Command Example

* A5 05 01 01 80 01 80 A1

*/

void moveHandler (uint8_t cmd, uint8_t param[], uint8_t n)

{

Serial.write(cmd);             // move command = 0x01

Serial.write(n);               // number of param = 4

for (int i=0;i<n;i++)          // param = 01 80 01 80

{

Serial.write (param[i]);

}

Mot1State = param[0];

Mot2State = param[2];

// Configure Inputs and Outputs

if (param[0] == 1){ digitalWrite(Motor1F,HIGH);

digitalWrite(Motor1R,LOW);

Serial.println(“Left Leg Forward”);

} else if (param[0] == 2) { digitalWrite(Motor1F,LOW);

digitalWrite(Motor1R,HIGH);

Serial.println(“Left Leg Backwards”);

}                                 else {digitalWrite(Motor1F,LOW);

digitalWrite(Motor1R,LOW);

Serial.println(“Left Leg Stop”);}

if (param[2] == 1){  digitalWrite(Motor2F,HIGH);

digitalWrite(Motor2R,LOW);

Serial.println(“Right Leg Forward”);

} else if (param[2] == 2) { digitalWrite(Motor2F,LOW);

digitalWrite(Motor2R,HIGH);

Serial.println(“Right Leg Backwards”);

}                                 else {digitalWrite(Motor2F,LOW);

digitalWrite(Motor2R,LOW);

Serial.println(“Right Leg Stop”);}

analogWrite(Motor1PWM,param[1]);

analogWrite(Motor2PWM,param[3]);

}                                // moveHandler

/*

* User Defined Command SERVO (0x41) Example

* Rotate servo to 90 degrees

* A5 02 41 90 76

*/

void dynstatHandler (uint8_t cmd, uint8_t param[], uint8_t n)

{

Serial.write(cmd);             // servo command = 0x41

Serial.write(n);               // number of param = 1

for (int i=0;i<n;i++)          // param = 90 degrees

{

Serial.write (param[i]);

}

}  // servoHandler

Telemetry and Custom Command Source Code

/*

* Telemetry and Custom Command Sample Arduino Code

*   Telemetry Example: Monitor an extended I/O register value and send to control panel display

*   Command Example:   Add Robot unique MOVE, BLINK, and SERVO commands

*/

#include <Robot3DoTBoard.h>     // instantiated as Robot3DoT at end of class header

#include <EEPROM.h>

#include <Wire.h>               // I2C support

#include <Servo.h>

// IMU Variables

long HoldTime = micros();

#define MPU6050_AUX_VDDIO          0x01   // R/W

#define MPU6050_SMPLRT_DIV         0x19   // R/W

#define MPU6050_CONFIG             0x1A   // R/W

#define MPU6050_GYRO_CONFIG        0x1B   // R/W

#define MPU6050_ACCEL_CONFIG       0x1C   // R/W

#define MPU6050_FF_THR             0x1D   // R/W

#define MPU6050_FF_DUR             0x1E   // R/W

#define MPU6050_MOT_THR            0x1F   // R/W

#define MPU6050_MOT_DUR            0x20   // R/W

#define MPU6050_ZRMOT_THR          0x21   // R/W

#define MPU6050_ZRMOT_DUR          0x22   // R/W

#define MPU6050_FIFO_EN            0x23   // R/W

#define MPU6050_I2C_MST_CTRL       0x24   // R/W

#define MPU6050_I2C_SLV0_ADDR      0x25   // R/W

#define MPU6050_I2C_SLV0_REG       0x26   // R/W

#define MPU6050_I2C_SLV0_CTRL      0x27   // R/W

#define MPU6050_I2C_SLV1_ADDR      0x28   // R/W

#define MPU6050_I2C_SLV1_REG       0x29   // R/W

#define MPU6050_I2C_SLV1_CTRL      0x2A   // R/W

#define MPU6050_I2C_SLV2_ADDR      0x2B   // R/W

#define MPU6050_I2C_SLV2_REG       0x2C   // R/W

#define MPU6050_I2C_SLV2_CTRL      0x2D   // R/W

#define MPU6050_I2C_SLV3_ADDR      0x2E   // R/W

#define MPU6050_I2C_SLV3_REG       0x2F   // R/W

#define MPU6050_I2C_SLV3_CTRL      0x30   // R/W

#define MPU6050_I2C_SLV4_ADDR      0x31   // R/W

#define MPU6050_I2C_SLV4_REG       0x32   // R/W

#define MPU6050_I2C_SLV4_DO        0x33   // R/W

#define MPU6050_I2C_SLV4_CTRL      0x34   // R/W

#define MPU6050_I2C_SLV4_DI        0x35   // R

#define MPU6050_I2C_MST_STATUS     0x36   // R

#define MPU6050_INT_PIN_CFG        0x37   // R/W

#define MPU6050_INT_ENABLE         0x38   // R/W

#define MPU6050_INT_STATUS         0x3A   // R

#define MPU6050_ACCEL_XOUT_H       0x3B   // R

#define MPU6050_ACCEL_XOUT_L       0x3C   // R

#define MPU6050_ACCEL_YOUT_H       0x3D   // R

#define MPU6050_ACCEL_YOUT_L       0x3E   // R

#define MPU6050_ACCEL_ZOUT_H       0x3F   // R

#define MPU6050_ACCEL_ZOUT_L       0x40   // R

#define MPU6050_TEMP_OUT_H         0x41   // R

#define MPU6050_TEMP_OUT_L         0x42   // R

#define MPU6050_GYRO_XOUT_H        0x43   // R

#define MPU6050_GYRO_XOUT_L        0x44   // R

#define MPU6050_GYRO_YOUT_H        0x45   // R

#define MPU6050_GYRO_YOUT_L        0x46   // R

#define MPU6050_GYRO_ZOUT_H        0x47   // R

#define MPU6050_GYRO_ZOUT_L        0x48   // R

#define MPU6050_EXT_SENS_DATA_00   0x49   // R

#define MPU6050_EXT_SENS_DATA_01   0x4A   // R

#define MPU6050_EXT_SENS_DATA_02   0x4B   // R

#define MPU6050_EXT_SENS_DATA_03   0x4C   // R

#define MPU6050_EXT_SENS_DATA_04   0x4D   // R

#define MPU6050_EXT_SENS_DATA_05   0x4E   // R

#define MPU6050_EXT_SENS_DATA_06   0x4F   // R

#define MPU6050_EXT_SENS_DATA_07   0x50   // R

#define MPU6050_EXT_SENS_DATA_08   0x51   // R

#define MPU6050_EXT_SENS_DATA_09   0x52   // R

#define MPU6050_EXT_SENS_DATA_10   0x53   // R

#define MPU6050_EXT_SENS_DATA_11   0x54   // R

#define MPU6050_EXT_SENS_DATA_12   0x55   // R

#define MPU6050_EXT_SENS_DATA_13   0x56   // R

#define MPU6050_EXT_SENS_DATA_14   0x57   // R

#define MPU6050_EXT_SENS_DATA_15   0x58   // R

#define MPU6050_EXT_SENS_DATA_16   0x59   // R

#define MPU6050_EXT_SENS_DATA_17   0x5A   // R

#define MPU6050_EXT_SENS_DATA_18   0x5B   // R

#define MPU6050_EXT_SENS_DATA_19   0x5C   // R

#define MPU6050_EXT_SENS_DATA_20   0x5D   // R

#define MPU6050_EXT_SENS_DATA_21   0x5E   // R

#define MPU6050_EXT_SENS_DATA_22   0x5F   // R

#define MPU6050_EXT_SENS_DATA_23   0x60   // R

#define MPU6050_MOT_DETECT_STATUS  0x61   // R

#define MPU6050_I2C_SLV0_DO        0x63   // R/W

#define MPU6050_I2C_SLV1_DO        0x64   // R/W

#define MPU6050_I2C_SLV2_DO        0x65   // R/W

#define MPU6050_I2C_SLV3_DO        0x66   // R/W

#define MPU6050_I2C_MST_DELAY_CTRL 0x67   // R/W

#define MPU6050_SIGNAL_PATH_RESET  0x68   // R/W

#define MPU6050_MOT_DETECT_CTRL    0x69   // R/W

#define MPU6050_USER_CTRL          0x6A   // R/W

#define MPU6050_PWR_MGMT_1         0x6B   // R/W

#define MPU6050_PWR_MGMT_2         0x6C   // R/W

#define MPU6050_FIFO_COUNTH        0x72   // R/W

#define MPU6050_FIFO_COUNTL        0x73   // R/W

#define MPU6050_FIFO_R_W           0x74   // R/W

#define MPU6050_WHO_AM_I           0x75   // R

// Defines for the bits, to be able to change

// between bit number and binary definition.

// By using the bit number, programming the sensor

// is like programming the AVR microcontroller.

// But instead of using “(1<<X)”, or “_BV(X)”,

// the Arduino “bit(X)” is used.

#define MPU6050_D0 0

#define MPU6050_D1 1

#define MPU6050_D2 2

#define MPU6050_D3 3

#define MPU6050_D4 4

#define MPU6050_D5 5

#define MPU6050_D6 6

#define MPU6050_D7 7

// AUX_VDDIO Register

#define MPU6050_AUX_VDDIO MPU6050_D7  // I2C high: 1=VDD, 0=VLOGIC

// CONFIG Register

// DLPF is Digital Low Pass Filter for both gyro and accelerometers.

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_DLPF_CFG0     MPU6050_D0

#define MPU6050_DLPF_CFG1     MPU6050_D1

#define MPU6050_DLPF_CFG2     MPU6050_D2

#define MPU6050_EXT_SYNC_SET0 MPU6050_D3

#define MPU6050_EXT_SYNC_SET1 MPU6050_D4

#define MPU6050_EXT_SYNC_SET2 MPU6050_D5

// Combined definitions for the EXT_SYNC_SET values

#define MPU6050_EXT_SYNC_SET_0 (0)

#define MPU6050_EXT_SYNC_SET_1 (bit(MPU6050_EXT_SYNC_SET0))

#define MPU6050_EXT_SYNC_SET_2 (bit(MPU6050_EXT_SYNC_SET1))

#define MPU6050_EXT_SYNC_SET_3 (bit(MPU6050_EXT_SYNC_SET1)|bit(MPU6050_EXT_SYNC_SET0))

#define MPU6050_EXT_SYNC_SET_4 (bit(MPU6050_EXT_SYNC_SET2))

#define MPU6050_EXT_SYNC_SET_5 (bit(MPU6050_EXT_SYNC_SET2)|bit(MPU6050_EXT_SYNC_SET0))

#define MPU6050_EXT_SYNC_SET_6 (bit(MPU6050_EXT_SYNC_SET2)|bit(MPU6050_EXT_SYNC_SET1))

#define MPU6050_EXT_SYNC_SET_7 (bit(MPU6050_EXT_SYNC_SET2)|bit(MPU6050_EXT_SYNC_SET1)|bit(MPU6050_EXT_SYNC_SET0))

// Alternative names for the combined definitions.

#define MPU6050_EXT_SYNC_DISABLED     MPU6050_EXT_SYNC_SET_0

#define MPU6050_EXT_SYNC_TEMP_OUT_L   MPU6050_EXT_SYNC_SET_1

#define MPU6050_EXT_SYNC_GYRO_XOUT_L  MPU6050_EXT_SYNC_SET_2

#define MPU6050_EXT_SYNC_GYRO_YOUT_L  MPU6050_EXT_SYNC_SET_3

#define MPU6050_EXT_SYNC_GYRO_ZOUT_L  MPU6050_EXT_SYNC_SET_4

#define MPU6050_EXT_SYNC_ACCEL_XOUT_L MPU6050_EXT_SYNC_SET_5

#define MPU6050_EXT_SYNC_ACCEL_YOUT_L MPU6050_EXT_SYNC_SET_6

#define MPU6050_EXT_SYNC_ACCEL_ZOUT_L MPU6050_EXT_SYNC_SET_7

// Combined definitions for the DLPF_CFG values

#define MPU6050_DLPF_CFG_0 (0)

#define MPU6050_DLPF_CFG_1 (bit(MPU6050_DLPF_CFG0))

#define MPU6050_DLPF_CFG_2 (bit(MPU6050_DLPF_CFG1))

#define MPU6050_DLPF_CFG_3 (bit(MPU6050_DLPF_CFG1)|bit(MPU6050_DLPF_CFG0))

#define MPU6050_DLPF_CFG_4 (bit(MPU6050_DLPF_CFG2))

#define MPU6050_DLPF_CFG_5 (bit(MPU6050_DLPF_CFG2)|bit(MPU6050_DLPF_CFG0))

#define MPU6050_DLPF_CFG_6 (bit(MPU6050_DLPF_CFG2)|bit(MPU6050_DLPF_CFG1))

#define MPU6050_DLPF_CFG_7 (bit(MPU6050_DLPF_CFG2)|bit(MPU6050_DLPF_CFG1)|bit(MPU6050_DLPF_CFG0))

// Alternative names for the combined definitions

// This name uses the bandwidth (Hz) for the accelometer,

// for the gyro the bandwidth is almost the same.

#define MPU6050_DLPF_260HZ    MPU6050_DLPF_CFG_0

#define MPU6050_DLPF_184HZ    MPU6050_DLPF_CFG_1

#define MPU6050_DLPF_94HZ     MPU6050_DLPF_CFG_2

#define MPU6050_DLPF_44HZ     MPU6050_DLPF_CFG_3

#define MPU6050_DLPF_21HZ     MPU6050_DLPF_CFG_4

#define MPU6050_DLPF_10HZ     MPU6050_DLPF_CFG_5

#define MPU6050_DLPF_5HZ      MPU6050_DLPF_CFG_6

#define MPU6050_DLPF_RESERVED MPU6050_DLPF_CFG_7

// GYRO_CONFIG Register

// The XG_ST, YG_ST, ZG_ST are bits for selftest.

// The FS_SEL sets the range for the gyro.

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_FS_SEL0 MPU6050_D3

#define MPU6050_FS_SEL1 MPU6050_D4

#define MPU6050_ZG_ST   MPU6050_D5

#define MPU6050_YG_ST   MPU6050_D6

#define MPU6050_XG_ST   MPU6050_D7

// Combined definitions for the FS_SEL values

#define MPU6050_FS_SEL_0 (0)

#define MPU6050_FS_SEL_1 (bit(MPU6050_FS_SEL0))

#define MPU6050_FS_SEL_2 (bit(MPU6050_FS_SEL1))

#define MPU6050_FS_SEL_3 (bit(MPU6050_FS_SEL1)|bit(MPU6050_FS_SEL0))

// Alternative names for the combined definitions

// The name uses the range in degrees per second.

#define MPU6050_FS_SEL_250  MPU6050_FS_SEL_0

#define MPU6050_FS_SEL_500  MPU6050_FS_SEL_1

#define MPU6050_FS_SEL_1000 MPU6050_FS_SEL_2

#define MPU6050_FS_SEL_2000 MPU6050_FS_SEL_3

// ACCEL_CONFIG Register

// The XA_ST, YA_ST, ZA_ST are bits for selftest.

// The AFS_SEL sets the range for the accelerometer.

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_ACCEL_HPF0 MPU6050_D0

#define MPU6050_ACCEL_HPF1 MPU6050_D1

#define MPU6050_ACCEL_HPF2 MPU6050_D2

#define MPU6050_AFS_SEL0   MPU6050_D3

#define MPU6050_AFS_SEL1   MPU6050_D4

#define MPU6050_ZA_ST      MPU6050_D5

#define MPU6050_YA_ST      MPU6050_D6

#define MPU6050_XA_ST      MPU6050_D7

// Combined definitions for the ACCEL_HPF values

#define MPU6050_ACCEL_HPF_0 (0)

#define MPU6050_ACCEL_HPF_1 (bit(MPU6050_ACCEL_HPF0))

#define MPU6050_ACCEL_HPF_2 (bit(MPU6050_ACCEL_HPF1))

#define MPU6050_ACCEL_HPF_3 (bit(MPU6050_ACCEL_HPF1)|bit(MPU6050_ACCEL_HPF0))

#define MPU6050_ACCEL_HPF_4 (bit(MPU6050_ACCEL_HPF2))

#define MPU6050_ACCEL_HPF_7 (bit(MPU6050_ACCEL_HPF2)|bit(MPU6050_ACCEL_HPF1)|bit(MPU6050_ACCEL_HPF0))

// Alternative names for the combined definitions

// The name uses the Cut-off frequency.

#define MPU6050_ACCEL_HPF_RESET  MPU6050_ACCEL_HPF_0

#define MPU6050_ACCEL_HPF_5HZ    MPU6050_ACCEL_HPF_1

#define MPU6050_ACCEL_HPF_2_5HZ  MPU6050_ACCEL_HPF_2

#define MPU6050_ACCEL_HPF_1_25HZ MPU6050_ACCEL_HPF_3

#define MPU6050_ACCEL_HPF_0_63HZ MPU6050_ACCEL_HPF_4

#define MPU6050_ACCEL_HPF_HOLD   MPU6050_ACCEL_HPF_7

// Combined definitions for the AFS_SEL values

#define MPU6050_AFS_SEL_0 (0)

#define MPU6050_AFS_SEL_1 (bit(MPU6050_AFS_SEL0))

#define MPU6050_AFS_SEL_2 (bit(MPU6050_AFS_SEL1))

#define MPU6050_AFS_SEL_3 (bit(MPU6050_AFS_SEL1)|bit(MPU6050_AFS_SEL0))

// Alternative names for the combined definitions

// The name uses the full scale range for the accelerometer.

#define MPU6050_AFS_SEL_2G  MPU6050_AFS_SEL_0

#define MPU6050_AFS_SEL_4G  MPU6050_AFS_SEL_1

#define MPU6050_AFS_SEL_8G  MPU6050_AFS_SEL_2

#define MPU6050_AFS_SEL_16G MPU6050_AFS_SEL_3

// FIFO_EN Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_SLV0_FIFO_EN  MPU6050_D0

#define MPU6050_SLV1_FIFO_EN  MPU6050_D1

#define MPU6050_SLV2_FIFO_EN  MPU6050_D2

#define MPU6050_ACCEL_FIFO_EN MPU6050_D3

#define MPU6050_ZG_FIFO_EN    MPU6050_D4

#define MPU6050_YG_FIFO_EN    MPU6050_D5

#define MPU6050_XG_FIFO_EN    MPU6050_D6

#define MPU6050_TEMP_FIFO_EN  MPU6050_D7

// I2C_MST_CTRL Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_MST_CLK0  MPU6050_D0

#define MPU6050_I2C_MST_CLK1  MPU6050_D1

#define MPU6050_I2C_MST_CLK2  MPU6050_D2

#define MPU6050_I2C_MST_CLK3  MPU6050_D3

#define MPU6050_I2C_MST_P_NSR MPU6050_D4

#define MPU6050_SLV_3_FIFO_EN MPU6050_D5

#define MPU6050_WAIT_FOR_ES   MPU6050_D6

#define MPU6050_MULT_MST_EN   MPU6050_D7

// Combined definitions for the I2C_MST_CLK

#define MPU6050_I2C_MST_CLK_0 (0)

#define MPU6050_I2C_MST_CLK_1  (bit(MPU6050_I2C_MST_CLK0))

#define MPU6050_I2C_MST_CLK_2  (bit(MPU6050_I2C_MST_CLK1))

#define MPU6050_I2C_MST_CLK_3  (bit(MPU6050_I2C_MST_CLK1)|bit(MPU6050_I2C_MST_CLK0))

#define MPU6050_I2C_MST_CLK_4  (bit(MPU6050_I2C_MST_CLK2))

#define MPU6050_I2C_MST_CLK_5  (bit(MPU6050_I2C_MST_CLK2)|bit(MPU6050_I2C_MST_CLK0))

#define MPU6050_I2C_MST_CLK_6  (bit(MPU6050_I2C_MST_CLK2)|bit(MPU6050_I2C_MST_CLK1))

#define MPU6050_I2C_MST_CLK_7  (bit(MPU6050_I2C_MST_CLK2)|bit(MPU6050_I2C_MST_CLK1)|bit(MPU6050_I2C_MST_CLK0))

#define MPU6050_I2C_MST_CLK_8  (bit(MPU6050_I2C_MST_CLK3))

#define MPU6050_I2C_MST_CLK_9  (bit(MPU6050_I2C_MST_CLK3)|bit(MPU6050_I2C_MST_CLK0))

#define MPU6050_I2C_MST_CLK_10 (bit(MPU6050_I2C_MST_CLK3)|bit(MPU6050_I2C_MST_CLK1))

#define MPU6050_I2C_MST_CLK_11 (bit(MPU6050_I2C_MST_CLK3)|bit(MPU6050_I2C_MST_CLK1)|bit(MPU6050_I2C_MST_CLK0))

#define MPU6050_I2C_MST_CLK_12 (bit(MPU6050_I2C_MST_CLK3)|bit(MPU6050_I2C_MST_CLK2))

#define MPU6050_I2C_MST_CLK_13 (bit(MPU6050_I2C_MST_CLK3)|bit(MPU6050_I2C_MST_CLK2)|bit(MPU6050_I2C_MST_CLK0))

#define MPU6050_I2C_MST_CLK_14 (bit(MPU6050_I2C_MST_CLK3)|bit(MPU6050_I2C_MST_CLK2)|bit(MPU6050_I2C_MST_CLK1))

#define MPU6050_I2C_MST_CLK_15 (bit(MPU6050_I2C_MST_CLK3)|bit(MPU6050_I2C_MST_CLK2)|bit(MPU6050_I2C_MST_CLK1)|bit(MPU6050_I2C_MST_CLK0))

// Alternative names for the combined definitions

// The names uses I2C Master Clock Speed in kHz.

#define MPU6050_I2C_MST_CLK_348KHZ MPU6050_I2C_MST_CLK_0

#define MPU6050_I2C_MST_CLK_333KHZ MPU6050_I2C_MST_CLK_1

#define MPU6050_I2C_MST_CLK_320KHZ MPU6050_I2C_MST_CLK_2

#define MPU6050_I2C_MST_CLK_308KHZ MPU6050_I2C_MST_CLK_3

#define MPU6050_I2C_MST_CLK_296KHZ MPU6050_I2C_MST_CLK_4

#define MPU6050_I2C_MST_CLK_286KHZ MPU6050_I2C_MST_CLK_5

#define MPU6050_I2C_MST_CLK_276KHZ MPU6050_I2C_MST_CLK_6

#define MPU6050_I2C_MST_CLK_267KHZ MPU6050_I2C_MST_CLK_7

#define MPU6050_I2C_MST_CLK_258KHZ MPU6050_I2C_MST_CLK_8

#define MPU6050_I2C_MST_CLK_500KHZ MPU6050_I2C_MST_CLK_9

#define MPU6050_I2C_MST_CLK_471KHZ MPU6050_I2C_MST_CLK_10

#define MPU6050_I2C_MST_CLK_444KHZ MPU6050_I2C_MST_CLK_11

#define MPU6050_I2C_MST_CLK_421KHZ MPU6050_I2C_MST_CLK_12

#define MPU6050_I2C_MST_CLK_400KHZ MPU6050_I2C_MST_CLK_13

#define MPU6050_I2C_MST_CLK_381KHZ MPU6050_I2C_MST_CLK_14

#define MPU6050_I2C_MST_CLK_364KHZ MPU6050_I2C_MST_CLK_15

// I2C_SLV0_ADDR Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV0_RW MPU6050_D7

// I2C_SLV0_CTRL Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV0_LEN0    MPU6050_D0

#define MPU6050_I2C_SLV0_LEN1    MPU6050_D1

#define MPU6050_I2C_SLV0_LEN2    MPU6050_D2

#define MPU6050_I2C_SLV0_LEN3    MPU6050_D3

#define MPU6050_I2C_SLV0_GRP     MPU6050_D4

#define MPU6050_I2C_SLV0_REG_DIS MPU6050_D5

#define MPU6050_I2C_SLV0_BYTE_SW MPU6050_D6

#define MPU6050_I2C_SLV0_EN      MPU6050_D7

// A mask for the length

#define MPU6050_I2C_SLV0_LEN_MASK 0x0F

// I2C_SLV1_ADDR Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV1_RW MPU6050_D7

// I2C_SLV1_CTRL Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV1_LEN0    MPU6050_D0

#define MPU6050_I2C_SLV1_LEN1    MPU6050_D1

#define MPU6050_I2C_SLV1_LEN2    MPU6050_D2

#define MPU6050_I2C_SLV1_LEN3    MPU6050_D3

#define MPU6050_I2C_SLV1_GRP     MPU6050_D4

#define MPU6050_I2C_SLV1_REG_DIS MPU6050_D5

#define MPU6050_I2C_SLV1_BYTE_SW MPU6050_D6

#define MPU6050_I2C_SLV1_EN      MPU6050_D7

// A mask for the length

#define MPU6050_I2C_SLV1_LEN_MASK 0x0F

// I2C_SLV2_ADDR Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV2_RW MPU6050_D7

// I2C_SLV2_CTRL Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV2_LEN0    MPU6050_D0

#define MPU6050_I2C_SLV2_LEN1    MPU6050_D1

#define MPU6050_I2C_SLV2_LEN2    MPU6050_D2

#define MPU6050_I2C_SLV2_LEN3    MPU6050_D3

#define MPU6050_I2C_SLV2_GRP     MPU6050_D4

#define MPU6050_I2C_SLV2_REG_DIS MPU6050_D5

#define MPU6050_I2C_SLV2_BYTE_SW MPU6050_D6

#define MPU6050_I2C_SLV2_EN      MPU6050_D7

// A mask for the length

#define MPU6050_I2C_SLV2_LEN_MASK 0x0F

// I2C_SLV3_ADDR Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV3_RW MPU6050_D7

// I2C_SLV3_CTRL Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV3_LEN0    MPU6050_D0

#define MPU6050_I2C_SLV3_LEN1    MPU6050_D1

#define MPU6050_I2C_SLV3_LEN2    MPU6050_D2

#define MPU6050_I2C_SLV3_LEN3    MPU6050_D3

#define MPU6050_I2C_SLV3_GRP     MPU6050_D4

#define MPU6050_I2C_SLV3_REG_DIS MPU6050_D5

#define MPU6050_I2C_SLV3_BYTE_SW MPU6050_D6

#define MPU6050_I2C_SLV3_EN      MPU6050_D7

// A mask for the length

#define MPU6050_I2C_SLV3_LEN_MASK 0x0F

// I2C_SLV4_ADDR Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV4_RW MPU6050_D7

// I2C_SLV4_CTRL Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_MST_DLY0     MPU6050_D0

#define MPU6050_I2C_MST_DLY1     MPU6050_D1

#define MPU6050_I2C_MST_DLY2     MPU6050_D2

#define MPU6050_I2C_MST_DLY3     MPU6050_D3

#define MPU6050_I2C_MST_DLY4     MPU6050_D4

#define MPU6050_I2C_SLV4_REG_DIS MPU6050_D5

#define MPU6050_I2C_SLV4_INT_EN  MPU6050_D6

#define MPU6050_I2C_SLV4_EN      MPU6050_D7

// A mask for the delay

#define MPU6050_I2C_MST_DLY_MASK 0x1F

// I2C_MST_STATUS Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV0_NACK MPU6050_D0

#define MPU6050_I2C_SLV1_NACK MPU6050_D1

#define MPU6050_I2C_SLV2_NACK MPU6050_D2

#define MPU6050_I2C_SLV3_NACK MPU6050_D3

#define MPU6050_I2C_SLV4_NACK MPU6050_D4

#define MPU6050_I2C_LOST_ARB  MPU6050_D5

#define MPU6050_I2C_SLV4_DONE MPU6050_D6

#define MPU6050_PASS_THROUGH  MPU6050_D7

// I2C_PIN_CFG Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_CLKOUT_EN       MPU6050_D0

#define MPU6050_I2C_BYPASS_EN   MPU6050_D1

#define MPU6050_FSYNC_INT_EN    MPU6050_D2

#define MPU6050_FSYNC_INT_LEVEL MPU6050_D3

#define MPU6050_INT_RD_CLEAR    MPU6050_D4

#define MPU6050_LATCH_INT_EN    MPU6050_D5

#define MPU6050_INT_OPEN        MPU6050_D6

#define MPU6050_INT_LEVEL       MPU6050_D7

// INT_ENABLE Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_DATA_RDY_EN    MPU6050_D0

#define MPU6050_I2C_MST_INT_EN MPU6050_D3

#define MPU6050_FIFO_OFLOW_EN  MPU6050_D4

#define MPU6050_ZMOT_EN        MPU6050_D5

#define MPU6050_MOT_EN         MPU6050_D6

#define MPU6050_FF_EN          MPU6050_D7

// INT_STATUS Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_DATA_RDY_INT   MPU6050_D0

#define MPU6050_I2C_MST_INT    MPU6050_D3

#define MPU6050_FIFO_OFLOW_INT MPU6050_D4

#define MPU6050_ZMOT_INT       MPU6050_D5

#define MPU6050_MOT_INT        MPU6050_D6

#define MPU6050_FF_INT         MPU6050_D7

// MOT_DETECT_STATUS Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_MOT_ZRMOT MPU6050_D0

#define MPU6050_MOT_ZPOS  MPU6050_D2

#define MPU6050_MOT_ZNEG  MPU6050_D3

#define MPU6050_MOT_YPOS  MPU6050_D4

#define MPU6050_MOT_YNEG  MPU6050_D5

#define MPU6050_MOT_XPOS  MPU6050_D6

#define MPU6050_MOT_XNEG  MPU6050_D7

// IC2_MST_DELAY_CTRL Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_I2C_SLV0_DLY_EN MPU6050_D0

#define MPU6050_I2C_SLV1_DLY_EN MPU6050_D1

#define MPU6050_I2C_SLV2_DLY_EN MPU6050_D2

#define MPU6050_I2C_SLV3_DLY_EN MPU6050_D3

#define MPU6050_I2C_SLV4_DLY_EN MPU6050_D4

#define MPU6050_DELAY_ES_SHADOW MPU6050_D7

// SIGNAL_PATH_RESET Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_TEMP_RESET  MPU6050_D0

#define MPU6050_ACCEL_RESET MPU6050_D1

#define MPU6050_GYRO_RESET  MPU6050_D2

// MOT_DETECT_CTRL Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_MOT_COUNT0      MPU6050_D0

#define MPU6050_MOT_COUNT1      MPU6050_D1

#define MPU6050_FF_COUNT0       MPU6050_D2

#define MPU6050_FF_COUNT1       MPU6050_D3

#define MPU6050_ACCEL_ON_DELAY0 MPU6050_D4

#define MPU6050_ACCEL_ON_DELAY1 MPU6050_D5

// Combined definitions for the MOT_COUNT

#define MPU6050_MOT_COUNT_0 (0)

#define MPU6050_MOT_COUNT_1 (bit(MPU6050_MOT_COUNT0))

#define MPU6050_MOT_COUNT_2 (bit(MPU6050_MOT_COUNT1))

#define MPU6050_MOT_COUNT_3 (bit(MPU6050_MOT_COUNT1)|bit(MPU6050_MOT_COUNT0))

// Alternative names for the combined definitions

#define MPU6050_MOT_COUNT_RESET MPU6050_MOT_COUNT_0

// Combined definitions for the FF_COUNT

#define MPU6050_FF_COUNT_0 (0)

#define MPU6050_FF_COUNT_1 (bit(MPU6050_FF_COUNT0))

#define MPU6050_FF_COUNT_2 (bit(MPU6050_FF_COUNT1))

#define MPU6050_FF_COUNT_3 (bit(MPU6050_FF_COUNT1)|bit(MPU6050_FF_COUNT0))

// Alternative names for the combined definitions

#define MPU6050_FF_COUNT_RESET MPU6050_FF_COUNT_0

// Combined definitions for the ACCEL_ON_DELAY

#define MPU6050_ACCEL_ON_DELAY_0 (0)

#define MPU6050_ACCEL_ON_DELAY_1 (bit(MPU6050_ACCEL_ON_DELAY0))

#define MPU6050_ACCEL_ON_DELAY_2 (bit(MPU6050_ACCEL_ON_DELAY1))

#define MPU6050_ACCEL_ON_DELAY_3 (bit(MPU6050_ACCEL_ON_DELAY1)|bit(MPU6050_ACCEL_ON_DELAY0))

// Alternative names for the ACCEL_ON_DELAY

#define MPU6050_ACCEL_ON_DELAY_0MS MPU6050_ACCEL_ON_DELAY_0

#define MPU6050_ACCEL_ON_DELAY_1MS MPU6050_ACCEL_ON_DELAY_1

#define MPU6050_ACCEL_ON_DELAY_2MS MPU6050_ACCEL_ON_DELAY_2

#define MPU6050_ACCEL_ON_DELAY_3MS MPU6050_ACCEL_ON_DELAY_3

// USER_CTRL Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_SIG_COND_RESET MPU6050_D0

#define MPU6050_I2C_MST_RESET  MPU6050_D1

#define MPU6050_FIFO_RESET     MPU6050_D2

#define MPU6050_I2C_IF_DIS     MPU6050_D4   // must be 0 for MPU-6050

#define MPU6050_I2C_MST_EN     MPU6050_D5

#define MPU6050_FIFO_EN        MPU6050_D6

// PWR_MGMT_1 Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_CLKSEL0      MPU6050_D0

#define MPU6050_CLKSEL1      MPU6050_D1

#define MPU6050_CLKSEL2      MPU6050_D2

#define MPU6050_TEMP_DIS     MPU6050_D3    // 1: disable temperature sensor

#define MPU6050_CYCLE        MPU6050_D5    // 1: sample and sleep

#define MPU6050_SLEEP        MPU6050_D6    // 1: sleep mode

#define MPU6050_DEVICE_RESET MPU6050_D7    // 1: reset to default values

// Combined definitions for the CLKSEL

#define MPU6050_CLKSEL_0 (0)

#define MPU6050_CLKSEL_1 (bit(MPU6050_CLKSEL0))

#define MPU6050_CLKSEL_2 (bit(MPU6050_CLKSEL1))

#define MPU6050_CLKSEL_3 (bit(MPU6050_CLKSEL1)|bit(MPU6050_CLKSEL0))

#define MPU6050_CLKSEL_4 (bit(MPU6050_CLKSEL2))

#define MPU6050_CLKSEL_5 (bit(MPU6050_CLKSEL2)|bit(MPU6050_CLKSEL0))

#define MPU6050_CLKSEL_6 (bit(MPU6050_CLKSEL2)|bit(MPU6050_CLKSEL1))

#define MPU6050_CLKSEL_7 (bit(MPU6050_CLKSEL2)|bit(MPU6050_CLKSEL1)|bit(MPU6050_CLKSEL0))

// Alternative names for the combined definitions

#define MPU6050_CLKSEL_INTERNAL    MPU6050_CLKSEL_0

#define MPU6050_CLKSEL_X           MPU6050_CLKSEL_1

#define MPU6050_CLKSEL_Y           MPU6050_CLKSEL_2

#define MPU6050_CLKSEL_Z           MPU6050_CLKSEL_3

#define MPU6050_CLKSEL_EXT_32KHZ   MPU6050_CLKSEL_4

#define MPU6050_CLKSEL_EXT_19_2MHZ MPU6050_CLKSEL_5

#define MPU6050_CLKSEL_RESERVED    MPU6050_CLKSEL_6

#define MPU6050_CLKSEL_STOP        MPU6050_CLKSEL_7

// PWR_MGMT_2 Register

// These are the names for the bits.

// Use these only with the bit() macro.

#define MPU6050_STBY_ZG       MPU6050_D0

#define MPU6050_STBY_YG       MPU6050_D1

#define MPU6050_STBY_XG       MPU6050_D2

#define MPU6050_STBY_ZA       MPU6050_D3

#define MPU6050_STBY_YA       MPU6050_D4

#define MPU6050_STBY_XA       MPU6050_D5

#define MPU6050_LP_WAKE_CTRL0 MPU6050_D6

#define MPU6050_LP_WAKE_CTRL1 MPU6050_D7

// Combined definitions for the LP_WAKE_CTRL

#define MPU6050_LP_WAKE_CTRL_0 (0)

#define MPU6050_LP_WAKE_CTRL_1 (bit(MPU6050_LP_WAKE_CTRL0))

#define MPU6050_LP_WAKE_CTRL_2 (bit(MPU6050_LP_WAKE_CTRL1))

#define MPU6050_LP_WAKE_CTRL_3 (bit(MPU6050_LP_WAKE_CTRL1)|bit(MPU6050_LP_WAKE_CTRL0))

// Alternative names for the combined definitions

// The names uses the Wake-up Frequency.

#define MPU6050_LP_WAKE_1_25HZ MPU6050_LP_WAKE_CTRL_0

#define MPU6050_LP_WAKE_2_5HZ  MPU6050_LP_WAKE_CTRL_1

#define MPU6050_LP_WAKE_5HZ    MPU6050_LP_WAKE_CTRL_2

#define MPU6050_LP_WAKE_10HZ   MPU6050_LP_WAKE_CTRL_3

// Default I2C address for the MPU-6050 is 0x68.

// But only if the AD0 pin is low.

// Some sensor boards have AD0 high, and the

// I2C address thus becomes 0x69.

#define MPU6050_I2C_ADDRESS 0x68

// Declaring an union for the registers and the axis values.

// The byte order does not match the byte order of

// the compiler and AVR chip.

// The AVR chip (on the Arduino board) has the Low Byte

// at the lower address.

// But the MPU-6050 has a different order: High Byte at

// lower address, so that has to be corrected.

// The register part “reg” is only used internally,

// and are swapped in code.

typedef union accel_t_gyro_union

{

struct

{

uint8_t x_accel_h;

uint8_t x_accel_l;

uint8_t y_accel_h;

uint8_t y_accel_l;

uint8_t z_accel_h;

uint8_t z_accel_l;

uint8_t t_h;

uint8_t t_l;

uint8_t x_gyro_h;

uint8_t x_gyro_l;

uint8_t y_gyro_h;

uint8_t y_gyro_l;

uint8_t z_gyro_h;

uint8_t z_gyro_l;

} reg;

struct

{

int x_accel;

int y_accel;

int z_accel;

int temperature;

int x_gyro;

int y_gyro;

int z_gyro;

} value;

};

// Use the following global variables and access functions to help store the overall

// rotation angle of the sensor

unsigned long last_read_time;

float         last_x_angle;  // These are the filtered angles

float         last_y_angle;

float         last_z_angle;

float         last_gyro_x_angle;  // Store the gyro angles to compare drift

float         last_gyro_y_angle;

float         last_gyro_z_angle;

void set_last_read_angle_data(unsigned long time, float x, float y, float z, float x_gyro, float y_gyro, float z_gyro) {

last_read_time = time;

last_x_angle = x;

last_y_angle = y;

last_z_angle = z;

last_gyro_x_angle = x_gyro;

last_gyro_y_angle = y_gyro;

last_gyro_z_angle = z_gyro;

}

inline unsigned long get_last_time() {return last_read_time;}

inline float get_last_x_angle() {return last_x_angle;}

inline float get_last_y_angle() {return last_y_angle;}

inline float get_last_z_angle() {return last_z_angle;}

inline float get_last_gyro_x_angle() {return last_gyro_x_angle;}

inline float get_last_gyro_y_angle() {return last_gyro_y_angle;}

inline float get_last_gyro_z_angle() {return last_gyro_z_angle;}

//  Use the following global variables and access functions

//  to calibrate the acceleration sensor

float    base_x_accel;

float    base_y_accel;

float    base_z_accel;

float    base_x_gyro;

float    base_y_gyro;

float    base_z_gyro;

int read_gyro_accel_vals(uint8_t* accel_t_gyro_ptr) {

// Read the raw values.

// Read 14 bytes at once,

// containing acceleration, temperature and gyro.

// With the default settings of the MPU-6050,

// there is no filter enabled, and the values

// are not very stable.  Returns the error value

accel_t_gyro_union* accel_t_gyro = (accel_t_gyro_union *) accel_t_gyro_ptr;

int error = MPU6050_read (MPU6050_ACCEL_XOUT_H, (uint8_t *) accel_t_gyro, sizeof(*accel_t_gyro));

// Swap all high and low bytes.

// After this, the registers values are swapped,

// so the structure name like x_accel_l does no

// longer contain the lower byte.

uint8_t swap;

#define SWAP(x,y) swap = x; x = y; y = swap

SWAP ((*accel_t_gyro).reg.x_accel_h, (*accel_t_gyro).reg.x_accel_l);

SWAP ((*accel_t_gyro).reg.y_accel_h, (*accel_t_gyro).reg.y_accel_l);

SWAP ((*accel_t_gyro).reg.z_accel_h, (*accel_t_gyro).reg.z_accel_l);

SWAP ((*accel_t_gyro).reg.t_h, (*accel_t_gyro).reg.t_l);

SWAP ((*accel_t_gyro).reg.x_gyro_h, (*accel_t_gyro).reg.x_gyro_l);

SWAP ((*accel_t_gyro).reg.y_gyro_h, (*accel_t_gyro).reg.y_gyro_l);

SWAP ((*accel_t_gyro).reg.z_gyro_h, (*accel_t_gyro).reg.z_gyro_l);

return error;

}

void calibrate_sensors() {

int                   num_readings = 10;

float                 x_accel = 0;

float                 y_accel = 0;

float                 z_accel = 0;

float                 x_gyro = 0;

float                 y_gyro = 0;

float                 z_gyro = 0;

accel_t_gyro_union    accel_t_gyro;

//Serial.println(“Starting Calibration”);

// Discard the first set of values read from the IMU

read_gyro_accel_vals((uint8_t *) &accel_t_gyro);

// Read and average the raw values from the IMU

for (int i = 0; i < num_readings; i++) {

read_gyro_accel_vals((uint8_t *) &accel_t_gyro);

x_accel += accel_t_gyro.value.x_accel;

y_accel += accel_t_gyro.value.y_accel;

z_accel += accel_t_gyro.value.z_accel;

x_gyro += accel_t_gyro.value.x_gyro;

y_gyro += accel_t_gyro.value.y_gyro;

z_gyro += accel_t_gyro.value.z_gyro;

delay(100);

}

x_accel /= num_readings;

y_accel /= num_readings;

z_accel /= num_readings;

x_gyro /= num_readings;

y_gyro /= num_readings;

z_gyro /= num_readings;

// Store the raw calibration values globally

base_x_accel = x_accel;

base_y_accel = y_accel;

base_z_accel = z_accel;

base_x_gyro = x_gyro;

base_y_gyro = y_gyro;

base_z_gyro = z_gyro;

//Serial.println(“Finishing Calibration”);

}

// Motor Variables

int Motor1F = 5;

int Motor1R = 10;

int Motor1PWM = A9;

volatile int Motor1Speed = 0;

int Motor2F = 19;

int Motor2R = 20;

int Motor2PWM = 6;

volatile int Motor2Speed = 0;

volatile int Mot1State = 0;

volatile int Mot2State = 0;

// Servo Variables

//

Robot3DoTBoard Robot3DoT;       // instantiated as Robot3DoT at end of class header

/*

* Command Example

* Step 1: Assign new command mnemonics ID numbers

*         In our example we will be adding 3 custom commands (2 new and one predefined).

*         The predefined MOVE command is intercepted and our robot unique code is to be

*         run instead. The MOVE command mnemonic ID 0x01 is already defined in Configure.h

*         The next two commands are new and assigned to the first two addresses in the

*         custom command address space 0x40 – 0x5F.

*/

#define DYNSTAT       0x41

const uint8_t CMD_LIST_SIZE = 2;   // we are adding 3 commands (MOVE, BLINK, SERVO)

/*

* Command Example

* Step 2: Register commands by linking IDs to their corresponding command handlers

*         In our example when the MOVE command is intercepted the moveHandler is to be run.

*         In a similar fashion the BLINK command calls the blinkHandler and SERVO the

*         servoHandler.

*/

void moveHandler (uint8_t cmd, uint8_t param[], uint8_t n);

void dynstatHandler (uint8_t cmd, uint8_t param[], uint8_t n);

Robot3DoTBoard::cmdFunc_t onCommand[CMD_LIST_SIZE] = {{MOVE,moveHandler}, {DYNSTAT,dynstatHandler}};

/*

* Telemetry Example

* Step 1: Instantiate packet

*         In our example we simulate a current sensor wired to MOTOR 2. MOTOR2_CURRENT_ID

*         is defined as 0x02 in Configure.h

*         To simulate the data stream coming from the sensor we will read ATmega32U4

*         Register OCR4D which controls the duty cycle of MOTOR 2.

*/

Packet motorPWM(MOTOR2_CURRENT_ID);  // initialize the packet properties to default values

void setup()

{

Serial.begin(9600);               // default = 115200

Robot3DoT.begin();

// Initialize Motor To Off

pinMode(Motor1F, OUTPUT);

pinMode(Motor1R, OUTPUT);

pinMode(Motor1PWM, OUTPUT);

pinMode(Motor2F, OUTPUT);

pinMode(Motor2R, OUTPUT);

pinMode(Motor2PWM, OUTPUT);

digitalWrite(Motor1F,LOW);

digitalWrite(Motor1R,LOW);

digitalWrite(Motor2F,LOW);

digitalWrite(Motor2R,LOW);

// Initialize IMU

int error;

uint8_t c;

/*

Serial.println(F(“InvenSense MPU-6050”));

Serial.println(F(“June 2012”));

*/

// Initialize the ‘Wire’ class for the I2C-bus.

Wire.begin();

// default at power-up:

//    Gyro at 250 degrees second

//    Acceleration at 2g

//    Clock source at internal 8MHz

//    The device is in sleep mode.

//

error = MPU6050_read (MPU6050_WHO_AM_I, &c, 1);

/*

Serial.print(F(“WHO_AM_I : “));

Serial.print(c,HEX);

Serial.print(F(“, error = “));

Serial.println(error,DEC);

*/

// According to the datasheet, the ‘sleep’ bit

// should read a ‘1’. But I read a ‘0’.

// That bit has to be cleared, since the sensor

// is in sleep mode at power-up. Even if the

// bit reads ‘0’.

error = MPU6050_read (MPU6050_PWR_MGMT_2, &c, 1);

/*

Serial.print(F(“PWR_MGMT_2 : “));

Serial.print(c,HEX);

Serial.print(F(“, error = “));

Serial.println(error,DEC);

*/

// Clear the ‘sleep’ bit to start the sensor.

MPU6050_write_reg (MPU6050_PWR_MGMT_1, 0);

//Initialize the angles

calibrate_sensors();

set_last_read_angle_data(millis(), 0, 0, 0, 0, 0, 0);

/*

* Command Example

* Step 3: Tell 3DoT Robot software about new commands

*

*

*/

Robot3DoT.setOnCommand(onCommand, CMD_LIST_SIZE);

/* Telemetry Example

* Step 2: Modify default values assigned to internal properties as needed.

*         Before a packet is created and sent, it is qualified. Specifically,

*         the data in a packet must change by some amount from the previous

*         packet and may not be sent with at a period less than some value.

*         In most cases you can leave these values at their default values.

*/

delay(1000);

}

void loop()

{

Robot3DoT.loop();

// Set Motor State to the Telemetry Read Value

if (Mot1State == 1){ digitalWrite(Motor1F,HIGH);

digitalWrite(Motor1R,LOW);

} else if (Mot1State == 2) { digitalWrite(Motor1F,LOW);

digitalWrite(Motor1R,HIGH);

}                                 else {digitalWrite(Motor1F,LOW);

digitalWrite(Motor1R,LOW);}

if (Mot2State == 1){  digitalWrite(Motor2F,HIGH);

digitalWrite(Motor2R,LOW);

} else if (Mot2State == 2) { digitalWrite(Motor2F,LOW);

digitalWrite(Motor2R,HIGH);

}                                 else {digitalWrite(Motor2F,LOW);

digitalWrite(Motor2R,LOW);}

analogWrite(Motor1PWM, Motor1Speed);

analogWrite(Motor2PWM, Motor2Speed);

if (micros() – HoldTime > 500000){

HoldTime = micros();

Serial.write(“”);

Serial.write(Mot1State);

Serial.write(Motor1Speed);

Serial.write(Mot2State);

Serial.write(Motor2Speed);

Serial.write(“”);

}

// Read IMU Settings

//IMU();

// Set Servos to IMU Setting

}

/*

* Command Example

* Step 4: Write command handlers

*/

/*

* User Defined Command BLINK (0x40) Example

* A5 01 40 E4

*/

/*

* Override MOVE (0x01) Command Example

* A5 05 01 01 80 01 80 A1

*/

void moveHandler (uint8_t cmd, uint8_t param[], uint8_t n)

{

Mot1State = param[0];

Mot2State = param[2];

// Configure Inputs and Output

Motor1Speed = param[1];

Motor2Speed = param[3];

Serial.write(cmd);             // move command = 0x01

Serial.write(n);               // number of param = 4

for (int i=0;i<n;i++)          // param = 01 80 01 80

{

Serial.write (param[i]);

}

}                                // moveHandler

/*

* User Defined Command SERVO (0x41) Example

* Rotate servo to 90 degrees

* A5 02 41 90 76

*/

void dynstatHandler (uint8_t cmd, uint8_t param[], uint8_t n)

{

Serial.write(cmd);             // servo command = 0x41

Serial.write(n);               // number of param = 1

for (int i=0;i<n;i++)          // param = 90 degrees

{

Serial.write (param[i]);

}

}  // servoHandler

// IMU LOOPS

void IMU()

{

int error;

double dT;

accel_t_gyro_union accel_t_gyro;

Serial.println(F(“”));

Serial.println(F(“MPU-6050”));

// Read the raw values.

cli();

error = read_gyro_accel_vals((uint8_t*) &accel_t_gyro);

sei();

// Get the time of reading for rotation computations

unsigned long t_now = millis();

Serial.print(F(“Read accel, temp and gyro, error = “));

Serial.println(error,DEC);

// Print the raw acceleration values

Serial.print(F(“accel x,y,z: “));

Serial.print(accel_t_gyro.value.x_accel, DEC);

Serial.print(F(“, “));

Serial.print(accel_t_gyro.value.y_accel, DEC);

Serial.print(F(“, “));

Serial.print(accel_t_gyro.value.z_accel, DEC);

Serial.println(F(“”));

// The temperature sensor is -40 to +85 degrees Celsius.

// It is a signed integer.

// According to the datasheet:

//   340 per degrees Celsius, -512 at 35 degrees.

// At 0 degrees: -512 – (340 * 35) = -12412

/*

Serial.print(F(“temperature: “));

dT = ( (double) accel_t_gyro.value.temperature + 12412.0) / 340.0;

Serial.print(dT, 3);

Serial.print(F(” degrees Celsius”));

Serial.println(F(“”));

// Print the raw gyro values.

Serial.print(F(“raw gyro x,y,z : “));

Serial.print(accel_t_gyro.value.x_gyro, DEC);

Serial.print(F(“, “));

Serial.print(accel_t_gyro.value.y_gyro, DEC);

Serial.print(F(“, “));

Serial.print(accel_t_gyro.value.z_gyro, DEC);

Serial.print(F(“, “));

Serial.println(F(“”));

*/

// Convert gyro values to degrees/sec

float FS_SEL = 131;

/*

float gyro_x = (accel_t_gyro.value.x_gyro – base_x_gyro)/FS_SEL;

float gyro_y = (accel_t_gyro.value.y_gyro – base_y_gyro)/FS_SEL;

float gyro_z = (accel_t_gyro.value.z_gyro – base_z_gyro)/FS_SEL;

*/

float gyro_x = (accel_t_gyro.value.x_gyro – base_x_gyro)/FS_SEL;

float gyro_y = (accel_t_gyro.value.y_gyro – base_y_gyro)/FS_SEL;

float gyro_z = (accel_t_gyro.value.z_gyro – base_z_gyro)/FS_SEL;

// Get raw acceleration values

//float G_CONVERT = 16384;

float accel_x = accel_t_gyro.value.x_accel;

float accel_y = accel_t_gyro.value.y_accel;

float accel_z = accel_t_gyro.value.z_accel;

// Get angle values from accelerometer

float RADIANS_TO_DEGREES = 180/3.14159;

//  float accel_vector_length = sqrt(pow(accel_x,2) + pow(accel_y,2) + pow(accel_z,2));

float accel_angle_y = atan(-1*accel_x/sqrt(pow(accel_y,2) + pow(accel_z,2)))*RADIANS_TO_DEGREES;

float accel_angle_x = atan(accel_y/sqrt(pow(accel_x,2) + pow(accel_z,2)))*RADIANS_TO_DEGREES;

float accel_angle_z = 0;

// Compute the (filtered) gyro angles

float dt =(t_now – get_last_time())/1000.0;

float gyro_angle_x = gyro_x*dt + get_last_x_angle();

float gyro_angle_y = gyro_y*dt + get_last_y_angle();

float gyro_angle_z = gyro_z*dt + get_last_z_angle();

// Compute the drifting gyro angles

float unfiltered_gyro_angle_x = gyro_x*dt + get_last_gyro_x_angle();

float unfiltered_gyro_angle_y = gyro_y*dt + get_last_gyro_y_angle();

float unfiltered_gyro_angle_z = gyro_z*dt + get_last_gyro_z_angle();

// Apply the complementary filter to figure out the change in angle – choice of alpha is

// estimated now.  Alpha depends on the sampling rate…

float alpha = 0.96;

float angle_x = alpha*gyro_angle_x + (1.0 – alpha)*accel_angle_x;

float angle_y = alpha*gyro_angle_y + (1.0 – alpha)*accel_angle_y;

float angle_z = gyro_angle_z;  //Accelerometer doesn’t give z-angle

// Update the saved data with the latest values

cli();

set_last_read_angle_data(t_now, angle_x, angle_y, angle_z, unfiltered_gyro_angle_x, unfiltered_gyro_angle_y, unfiltered_gyro_angle_z);

sei();

//  Send the data to the serial port

//  Serial.print(F(“DEL:”));              //Delta T

//  Serial.print(dt, DEC);

//  Serial.print(F(“#ACC:”));              //Accelerometer angle

//  Serial.print(accel_angle_x, 2);

//  Serial.print(F(“,”));

//  Serial.print(accel_angle_y, 2);

//  Serial.print(F(“,”));

//  Serial.print(accel_angle_z, 2);

//  Serial.print(F(“#GYR:”));

//  Serial.print(unfiltered_gyro_angle_x, 2);        //Gyroscope angle

//  Serial.print(F(“,”));

//  Serial.print(unfiltered_gyro_angle_y, 2);

//  Serial.print(F(“,”));

//  Serial.print(unfiltered_gyro_angle_z, 2);

//  Serial.print(F(“#FIL:”));             //Filtered angle

//  Serial.print(angle_x, 2);

//  Serial.print(F(“,”));

//  Serial.print(angle_y, 2);

//  Serial.print(F(“,”));

//  Serial.print(angle_z, 2);

//  Serial.println(F(“”));

}

// ——————————————————–

// MPU6050_read

//

// This is a common function to read multiple bytes

// from an I2C device.

//

// It uses the boolean parameter for Wire.endTransMission()

// to be able to hold or release the I2C-bus.

// This is implemented in Arduino 1.0.1.

//

// Only this function is used to read.

// There is no function for a single byte.

//

int MPU6050_read(int start, uint8_t *buffer, int size)

{

int i, n, error;

Wire.beginTransmission(MPU6050_I2C_ADDRESS);

n = Wire.write(start);

if (n != 1)

return (-10);

n = Wire.endTransmission(false);    // hold the I2C-bus

if (n != 0)

return (n);

// Third parameter is true: relase I2C-bus after data is read.

Wire.requestFrom(MPU6050_I2C_ADDRESS, size, true);

i = 0;

while(Wire.available() && i<size)

{

buffer[i++]=Wire.read();

}

if ( i != size)

return (-11);

return (0);  // return : no error

}

// ——————————————————–

// MPU6050_write

//

// This is a common function to write multiple bytes to an I2C device.

//

// If only a single register is written,

// use the function MPU_6050_write_reg().

//

// Parameters:

//   start : Start address, use a define for the register

//   pData : A pointer to the data to write.

//   size  : The number of bytes to write.

//

// If only a single register is written, a pointer

// to the data has to be used, and the size is

// a single byte:

//   int data = 0;        // the data to write

//   MPU6050_write (MPU6050_PWR_MGMT_1, &c, 1);

//

int MPU6050_write(int start, const uint8_t *pData, int size)

{

int n, error;

Wire.beginTransmission(MPU6050_I2C_ADDRESS);

n = Wire.write(start);        // write the start address

if (n != 1)

return (-20);

n = Wire.write(pData, size);  // write data bytes

if (n != size)

return (-21);

error = Wire.endTransmission(true); // release the I2C-bus

if (error != 0)

return (error);

return (0);         // return : no error

}

// ——————————————————–

// MPU6050_write_reg

//

// An extra function to write a single register.

// It is just a wrapper around the MPU_6050_write()

// function, and it is only a convenient function

// to make it easier to write a single register.

//

int MPU6050_write_reg(int reg, uint8_t data)

{

int error;

error = MPU6050_write(reg, &data, 1);

return (error);

}
